  • HT8802-M seriesload is a precision programmable DC electronic load controlled by a high-performance microprocessor.
  • 5-inch TFT true color LCD display with Chinese and English menu.
  • Offers 4 basic working modes (CC/CV/CR/CW) and 10 functional modes.
  • With comprehensive protection, over-heat protection, over-current protection, over-power protection, over-voltage protection, loop oscillation protection.
  • Rich interfaces configuration. LAN, USB and analog interfaces to fit your versatile solution and testing needs.

4 basic working modes CC/CV/CR/CW and 10 functional modes multiple extended function modes:

  • Short test function
  • DYNA dynamic test function
  • OCP over current protection mode
  • BATT battery mode
  • EFFT load effect mode
  • SWEEP dynamic frequency conversion scanning function
  • TIMEING measurement function
  • OVP over voltage protection mode
  • AUTO mode
  • LIST function
  • Timing test mode.
  • OVP over voltage protection mode

Technical parameters

Model HT8802 HT8802B HT8802C
Input voltage 15V 150V 50V 500V 15V 150V
Input current 24A 240A 12A 120A 50A 500A
Input power 8000W
Min.operation voltage 1.5V@240A 2V@120A 1.5V@500A
Min rise time@ FS current 100us 100us 100us
CV mode
Range 15V 150V 50V 500V 15V 150V
Resolution 0.2mV 2mV 0.7mV 7mV 0.2mV 2mV
Accuracy ±(0.05%+0.05%FS)
CC mode
Range 24A 240A 12A 120A 50A 500A
Resolution 0.3mA 3mA 0.1mA 1mA 0.7mA 7mA
Accuracy ±(0.05%+0.05%FS)
CR mode
Range 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ
Resolution 16Bits
Accuracy ±0.2%
CW mode
Range 8000W
Resolution 16Bits
Accuracy ±（0.2%+0.2%FS）
Dynamic mode
Ta＆Tb 10us~50s
Min.resolution 10us
Min. rise time 2.5A/us 1A/us 5A/us
Read-back voltage
Range 15V 150V 50V 500V 15V 150V
Resolution 0.1mV 1mV 0.3mV 3mV 0.1mV 1mV
Accuracy ±(0.025%+0.025%FS)
Read-back current
Range 24A 240A 12A 120A 50A 500A
Resolution 0.1mA 1mA 0.09mA 0.9mA 0.3mA 3mA
Accuracy ±(0.05%+0.05%FS)
Read-back ripple
Range(U/I) 150V/240A 500V/120A 150V/500A
Bandwidth 10Hz~250kHz
Accuracy ±1%
Protection range
Over-power protection 8400W 8400W 8400W
Over-current protection 252A 126A 525A
Over-voltage protection 158V 525V 158V
Over-temperature protection ≒85℃
Specification
Dimension (D*W*H) 720.5mm*483mm*355mm
Gross Weight 80Kg



Model HT8103B HT8103C HT8123B HT8123C
Input voltage 50V 500V 15V 150V 50V 500V 15V 150V
Input current 24A 240A 50A 500A 24A 240A 50A 500A
Input power 10kW 12kW
Min.operation voltage 1.5V@240A 1.5V@500A 2.5V@240A 1.5V@500A
Min rise time@ FS current 100us 100us 100us 100us
CV mode
Range 50V 500V 15V 150V 50V 500V 15V 150V
Resolution 0.7mV 7mV 0.2mV 2mV 0.7mV 7mV 0.2mV 2mV
Accuracy ±(0.05%+0.05%FS)
CC mode
Range 24A 240A 50A 500A 24A 240A 50A 500A
Resolution 0.3mA 3mA 0.7mA 7mA 0.3mA 3mA 0.7mA 7mA
Accuracy ±(0.1%+0.1%FS)
CR mode
Range 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ
Resolution 16Bits
Accuracy ±0.2%
CW mode
Range 10kW 12kW
Resolution 16Bits
Accuracy ±（0.2%+0.25%FS）
Dynamic mode
Ta＆Tb 10us~50s
Min.resolution 10us
Min. rise time 2.5A/us 5A/us 2.5A/us 5A/us
Read-back voltage
Range 50V 500V 50V 500V 50V 500V 15V 150V
Resolution 0.3mV 3mV 0.1mV 1mV 0.3mV 3mV 0.1mV 1mV
Accuracy ±(0.025%+0.025%FS)
Read-back current
Range 24A 240A 50A 500A 24A 240A 50A 500A
Resolution 0.1mA 1mA 0.3mA 3mA 0.1mA 1mA 0.3mA 3mA
Accuracy ±(0.05%+0.05%FS)
Read-back ripple
Range(U/I) 500V/240A 150V/500A 500V/240A 150V/500A
Bandwidth 10Hz~250kHz
Accuracy ±1%
Protection range
Over-power protection 10500W 12600W
Over-current protection 252A 525A 252A 525A
Over-voltage protection 525V 158V 525V 158V
Over-temperature protection ≒85℃
Specification
Dimension (D*W*H) 720.5mm*483mm*355mm
Gross Weight 88Kg 96Kg





Model H
T
8143B		 H
T
8143C		 H
T
8163B		 H
T
8163C
Input voltage 50V 500V 15V 150V 50V 500V 15V 150V
Input current 24A 240A 50A 500A 24A 240A 50A 500A
Input power 14kW 16kW
Min.operation voltage 2V@240A 1.5V@500A 2.5V@240A 1.5V@500A
Min rise time@ FS current 100us 100us 100us 100us
CV mode
Range 50V 500V 15V 150V 50V 500V 15V 150V
Resolution 0.7mV 7mV 0.2mV 2mV 0.7mV 7mV 0.2mV 2mV
Accuracy ±(0.05%+0.05%FS)
CC mode
Range 24A 240A 50A 500A 24A 240A 50A 500A
Resolution 0.3mA 3mA 0.7mA 7mA 0.3mA 3mA 0.7mA 7mA
Accuracy ±(0.1%+0.1%FS)
CR mode
Range 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ
Resolution 16Bits
Accuracy ±0.2%
CW mode
Range 14kW 16kW
Resolution 16Bits
Accuracy ±（0.2%+0.2%FS）
Dynamic mode
Ta＆Tb 10us~50s
Min.resolution 10us
Min. rise time 2.5A/us 5A/us 2.5A/us 5A/us
Read-back voltage
Range 50V 500V 50V 500V 50V 500V 15V 150V
Resolution 0.3mV 3mV 0.1mV 1mV 0.3mV 3mV 0.1mV 1mV
Accuracy ±(0.025%+0.025%FS)
Read-back current
Range 24A 240A 50A 500A 24A 240A 50A 500A
Resolution 0.1mA 1mA 0.3mA 3mA 0.1mA 1mA 0.3mA 3mA
Accuracy ±(0.05%+0.05%FS)
Read-back ripple
Range(U/I) 500V/240A 150V/500A 500V/240A 150V/500A
Bandwidth 10Hz~250kHz
Accuracy ±1%
Protection range
Over-power protection 14700W 16800W
Over-current protection 252A 525A 252A 525A
Over-voltage protection 525V 158V 525V 158V
Over-temperature protection ≒85℃
Specification
Dimension (D*W*H) 720.5mm*483mm*530mm
Gross Weight 120Kg 128Kg



Model H
T
8183B		 H
T
8183C		 H
T
8203B		 H
T
8203C
Input voltage 50V 500V 15V 150V 50V 500V 15V 150V
Input current 24A 240A 50A 500A 24A 240A 50A 500A
Input power 18kW 20kW
Min.operation voltage 2V@240A 1.5V@500A 2V@240A 1.5V@500A
Min rise time@ FS current 100us 100us 100us 100us
CV mode
Range 50V 500V 15V 150V 50V 500V 15V 150V
Resolution 0.7mV 7mV 0.2mV 2mV 0.7mV 7mV 0.2mV 2mV
Accuracy ±(0.05%+0.05%FS)
CC mode
Range 24A 240A 50A 500A 24A 240A 50A 500A
Resolution 0.3mA 3mA 0.7mA 7mA 0.3mA 3mA 0.7mA 7mA
Accuracy ±(0.1%+0.1%FS)
CR mode
Range 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ 0.1Ω~7.5kΩ
Resolution 16Bits
Accuracy ±0.2%
CW mode
Range 18kW 20kW
Resolution 16Bits
Accuracy ±（0.2%+0.2%FS）
Dynamic mode
Ta＆Tb 10us~50s
Min.resolution 10us
Min. rise time 2.5A/us 5A/us 2.5A/us 5A/us
Read-back voltage
Range 50V 500V 50V 500V 50V 500V 15V 150V
Resolution 0.3mV 3mV 0.1mV 1mV 0.3mV 3mV 0.1mV 1mV
Accuracy ±(0.025%+0.025%FS)
Read-back voltage
Range 24A 240A 50A 500A 24A 240A 50A 500A
Resolution 0.1mA 1mA 0.3mA 3mA 0.1mA 1mA 0.3mA 3mA
Accuracy ±(0.05%+0.05%FS)
Read-back ripple
Range(U/I) 500V/240A 150V/500A 500V/240A 150V/500A
Bandwidth 10Hz~250kHz
Accuracy ±1%
Protection range
Over-power protection 18900W 21000W
Over-current protection 252A 525A 252A 525A
Over-voltage protection 525V 158V 525V 158V
Over-temperature protection ≒85℃
Specification
Dimension (D*W*H) 720.5mm*483mm*530mm 720.5mm*483mm*705mm
Gross Weight 136Kg 150Kg
